Hirose FH72-11S-0.3SHW Connector Product Overview:
 | makers | Hirose |
| Manufacturer's Code | FH72-11S-0.3SHW | |
| Product Description | CONN FPC TOP 11POS 0.3MM R/A,11 pos FPC Connector Contacts, Top 0.012" (0.30mm) Surface Mount, Right Angle |
Hirose FH72-11S-0.3SHW Connector Product Attributes:
| typology | descriptive |
| form | Connectors, Interconnects |
| FFC, FPC (Flat Flexible) Connectors | |
| FFC, FPC (Flat Flexible) Connector Assemblies | |
| makers | Hirose Electric Co Ltd |
| range | FH72 |
| wrap | Tape and Reel (TR) |
| Flat flexible type | FPC |
| Installation type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top |
| pin position | 11 |
| spacing | 0.012"（0.30mm） |
| nock (of a bow) | soldered |
| FFC, FCB Thickness | 0.20mm |
| board height | 0.035"（0.88mm） |
| lockout function | trigger lock |
| Cable End Type | notched |
| Contact Material | copper alloy |
| Contact surface treatment | gilt |
| Housing Material | Liquid Crystal Polymers (LCP) |
| Actuator Materials | Polyamide (PA), Nylon |
| rated voltage | 30V |
| operating temperature | -55°C ~ 85°C |
| Material flammability rating | UL94 V-0 |
| Rated current (amps) | 0.2A |
| Contact surface treatment thickness | 1.25µin（0.03µm） |
| Housing Color | rice-colored |
| Actuator Color | ferrous |
| Number of mating times | 10 |
Hirose FH72-11S-0.3SHW Connector Product (Series) Description:
This product is the FH72 series FFC/FPC (Flat Flexible) connector manufactured by Hirose Electric Co Ltd. Designed for surface mount applications, it features a right-angle mounting method and is suitable for a variety of high-density circuit board connections. The connectors feature an 11-pin design with a pitch of 0.30mm and a solder termination to ensure reliable electrical contact. The contact material is copper alloy with gold-plated surface, which has excellent conductivity and is suitable for electrical environments with a rated voltage of 30V and a rated current of 0.2A. The connectors have a liquid crystal polymer (LCP) shell with good heat and chemical resistance, and are equipped with a trigger lock function to ensure a stable connection. With an operating temperature range of -55°C to 85°C and a UL94 V-0 flammability rating, the connectors are adapted to demanding electronics environments. In addition, the connectors can be mated up to 10 times to meet the needs of long-time use. Overall, the FH72 series FFC/FPC connectors are characterized by high density, small size, and durability, and are suitable for high-precision connections in all types of electronic devices.
