I-PEX 81787-100B-03-D builds high-reliability mini high-speed connectivityWith the development of intelligent manufacturing, industrial automation, machine vision, and high-performance electronic equipment, the requirements for connection components inside the equipment are increasingly stringent. They must meet installation needs in limited spaces while ensuring stability and reliability during high-speed signal transmission. Micro coaxial cables, with their advantages of low loss, high shielding, and small size, are gradually becoming an important solution for internal connections in precision electronic equipment.
I-PEX 81787-100B-03-D is an I-PEX CABLINE-UY series 10Pin Micro Coaxial Harness (miniature coaxial harness component). This product adopts a 10-core high-density connection structure and realizes signal transmission within the device through miniature coaxial cables. Compared with traditional connection harness solutions, the CABLINE-UY series has obvious advantages in space utilization, signal integrity, and connection reliability, and can meet the application needs of modern electronic equipment for miniaturization and high-performance connections.
This model product is mainly used in industrial equipment, visual inspection systems, high-speed display modules, medical electronic equipment, intelligent terminals, and other space-limited electronic products, providing stable and reliable data connections between internal modules of the equipment.
I-PEX CABLINE-UY series 81787-100B-03-D product advantagesAs one of the CABLINE-UY series products, I-PEX 81787-100B-03-D has various application advantages:
Miniaturized structural design, optimized equipment space layout
The product adopts a compact connector structure, combined with a miniature coaxial cable design, which can effectively reduce the internal wiring space occupied and is suitable for slim and high-density equipment design.
Excellent high-speed signal transmission performance
Miniature coaxial cables have good signal transmission characteristics, which can reduce signal attenuation and interference during transmission and are suitable for high-speed data, image, and control signal connections.
Good electromagnetic compatibility performance
The coaxial shielding structure can effectively suppress external electromagnetic interference and reduce signal crosstalk between lines, thereby improving the stability of system operation.
High-reliability connection application capability
Precision connector design ensures connection stability and meets the durability requirements of industrial equipment and long-term operating equipment.
Flexible adaptation to different application scenarios
According to the equipment structure requirements, it is possible to match the design for harness length, installation direction, and application environment, improving the flexibility of product application.
Selection, compatibility, and alternative solutions reference and suggestionsIn the actual project development and product mass production stage, customers are concerned not only about product performance but also about supply cycle, procurement cost, and long-term supply guarantee. When the original factory wiring has a long delivery period, limited procurement channels, or the need for cost optimization, finding a reliable compatible alternative solution becomes an important way to enhance project stability.
In terms of the I-PEX 81787-100B-03-D product, our company can provide a compatible and alternative cable assembly solution for the I-PEX 81787-100B-03-D. This includes connector matching, cable selection, electrical performance analysis, and structural size optimization based on the original factory product specifications to ensure that the alternative product can meet the actual application requirements.
It is recommended to focus on confirming the following when considering compatible alternatives:
● Connector specification consistency: Confirm whether the number of pins, connector structure, interface size, and installation method match.
●Cable performance requirements: Select the appropriate specification of Micro Coaxial cable according to the type of transmitted signal.
● Wiring harness size parameters: Confirm the length of the wiring harness, bending direction, and internal installation space of the device.
●Reliability verification requirements: Verify the alternative solutions through conductivity performance, signal testing, mechanical reliability testing, etc.
Ensure that suppliers have continuous development and mass production capabilities.
Our company focuses on the research and development and manufacturing of precision electronic harnesses, and can provide compatible and alternative harness solutions for I-PEX 81787-100B-03-D, I-PEX 82859-100B-02-D and other product series. We support customers in completing the entire process from design, sample verification to mass production, helping enterprises reduce supply chain risks.
CABLINE-UY series helps to upgrade precision equipment connectionsI-PEX 81787-100B-03-D acts as a 10Pin miniature coaxial cable assembly in the CABLINE-UY series, providing reliable support for internal connections of modern electronic devices with high-density connections, miniaturized design, and stable data transmission capabilities.
